Description
Bosch 275l/h @5bar In-line fuel pump.
This fuel pump kit is a direct replacement for the Bosch 044 (Bosch part number 0 580 254 044)
It is capable of providing 275l/h @ 5bar (8bar).
Flows ~10% higher than 044 at 7bar
Weighs 15% less than 044 at 860g
Draws 14amps (1A) with 5 bar fuel rail pressure and 15amps (1A) at 8bar
M18x1.5 inlet fitting and M12x1.5 outlet fitting
External non return valve
Pressure relief valve 8-10bar
Not suitable for voltage regulation (variable speed control)
Compatible with gasoline and diesel
Operating Voltage: 6 – 15V
The Bosch 200 supercedes the Bosch 044 one of the most popular aftermarket fuel pumps and is sometimes refered to as the “Bosch Motorsport Fuel Pump”.
